ARES P

The ARES P is a pressurised pneumatic seed drill, available in various working widths ranging from 4 m to 7,2 m. Capable of performing from conventional seeding to minimum tillage depending on the type of boom equipped. Maximum efficiency and the highest field performance thanks to the hopper pressurisation system.

Pressurised hopper.
Double external distribution head.
Quick and easy calibration from ISOBUS monitor.
Interchangeable modular roller metering unit with electric drive.
ISOBUS electric drive.
Efficient hopper emptying.
Increased seed distribution capacity.
Reduced hydraulic oil consumption in the tractor.
Increased homogeneity of product distribution.
Optimum product preservation due to hermetic sealing.
Lower tractor fuel consumption.
Floating chassis in three sections.
Easy and intuitive operation from the tractor cab.
  400/32 400/32 450/36 450/36 500/40 500/40 600/48 600/48 700/48 700/48
Furrower type TINE COULTER
Working width [m] 4 4,5 5 6 7
Number of rows 3 4 3 4 3 4 3 4 3 4
Transport width [m] 3,05
Number of rows 32 36 40 48
Row spacing [cm] 12,5 14,6 0,0
Hopper capacity [l] 2000
Weight of machine with track eradicators [kg] (1) 1540 1650 1760 - 1800 1825 1925 1980 - 2050
Weight of machine with cultivator [kg] (2) 1880 N/A 2115 N/A 2190 N/A 2335 N/A - N/A
Reload height [cm] 230
Reload opening [cm] 110X105
Coupling category Cat. III
Minimum power required [hp] (3) 120 120 140 160 180
Main wheels/tyres Choose between wheels [10.75-15.3] and flotation wheels [340/55-16]
Metering unit drive ISOBUS electric
Speed connection Optional, see chap. "GNSS receivers"
Turbine drive Choose between mechanical with PTO drive shaft at 1000 rpm or hydraulic
Required hydraulic flow [l/min] 30
Tine spring harrow Two rows of straight tines. Standard.
Removable selector sieve Standard
Seed dose calibration kit Side, easy and precise
Controller/monitor From ISOBUS monitor (optional, see chap. "Control monitors")
Signal lights and work lights Standard
Depth control wheel equipment Standard: 2 wheels on wings (1 on each wing) and 0 wheels on central part
Main wheel scrapers Standard
Half-width cut-off  Optional, can be manual or automatic with GPS antenna
  400/32 450/36 500/40 600/48
Furrower type SUFFOLK COULTER
Working width [m] 4 4,5 5 6
Number of rows 3 3 3 3
Transport width [m] 3,05
Number of rows 32 36 40 48
Row spacing [cm] 12,5 12,5 12,5 12,5
Hopper capacity [l] 2000
Weight of machine with track eradicators [kg] (1) - - 1860 1965
Weight of machine with cultivator [kg] (2) - - 2270 2375
Reload height [cm] 230
Reload opening [cm] 110X105
Coupling category Cat. III
Minimum power required [hp] (3) 120 140 160
Main wheels/tyres Choose between wheels [10.75-15.3] and flotation wheels [340/55-16]
Metering unit drive ISOBUS electric
Speed connection Optional, see chap. "GNSS receivers"
Turbine drive Choose between mechanical with PTO drive shaft at 1000 rpm or hydraulic
Required hydraulic flow [l] 30
Tine spring harrow Two rows of straight tines. Standard.
Removable selector sieve Standard
Seed dose calibration kit Side, easy and precise
Controller/monitor From ISOBUS monitor (optional, see chap. "Control monitors")
Signal lights and work lights Standard
Depth control wheel equipment Standard: 2 wheels on wings (1 on each wing) and 0 wheels on central part
Main wheel scrapers Standard
Half-width cut-off  Optional, can be manual or automatic with GPS antenna
  400/32 450/36 500/40 600/48
Furrower type DISC
Working width [m] 4 4,5 5 6
Number of rows 2 2 2 2
Transport width [m] 3,05
Number of rows 32 36 40 48
Row spacing [cm] 12,5 12,5 12,5 12,5
Hopper capacity [l] 2000
Weight of machine with track eradicators [kg] (1) - - 2040 2105
Weight of machine with cultivator [kg] (2) - - 2430 2515
Reload height [cm] 230
Reload opening [cm] 110X105
Coupling category Cat. III
Minimum power required [hp] (3) 120 140 160
Main wheels/tyres Choose between wheels [10.75-15.3] and flotation wheels [340/55-16]
Metering unit drive ISOBUS electric
Speed connection Optional, see chap. "GNSS receivers"
Turbine drive Choose between mechanical with PTO drive shaft at 1000 rpm or hydraulic
Required hydraulic flow [l] 30
Tine spring harrow Two rows of straight tines. Standard.
Removable selector sieve Standard
Seed dose calibration kit Side, easy and precise
Controller/monitor From ISOBUS monitor (optional, see chap. "Control monitors")
Signal lights and work lights Standard
Depth control wheel equipment - Standard: 2 wheels on wings (1 on each wing) and 0 wheels on central part
Main wheel scrapers Standard
Half-width cut-off  Optional, can be manual or automatic with GPS antenna
  400/24 450/28 500/32 600/38
Furrower type DOUBLE DISC WITH PARALLELOGRAM
Working width [m] 4 4,5 5 6
Number of rows 2 2 2 2
Transport width [m] 3,05
Number of rows 24 28 32 38
Row spacing [cm] 16,7 16,1 15,6 15,8
Hopper capacity [l] 2000
Weight of machine with track eradicators [kg] (1) 1860 - 2170 2325
Weight of machine with cultivator [kg] (2) 2200 - 2560 2735
Reload height [cm] 230
Reload opening [cm] 110X105
Coupling category Cat. III
Minimum power required [hp] (3) 120 140 160
Main wheels/tyres Choose between wheels [10.75-15.3] and flotation wheels [340/55-16]
Metering unit drive ISOBUS electric
Speed connection Optional, see chap. "GNSS receivers"
Turbine drive Choose between mechanical with PTO drive shaft at 1000 rpm or hydraulic
Required hydraulic flow [l] 30
Tine spring harrow Single with angled tines. Standard.
Removable selector sieve Standard
Seed dose calibration kit Side, easy and precise
Controller/monitor From ISOBUS monitor (optional, see chap. "Control monitors")
Signal lights and work lights Standard
Depth control wheel equipment Standard: 2 wheels on wings (1 on each wing) and 0 wheels on central part
Main wheel scrapers Standard
Half-width cut-off  Optional, can be manual or automatic with GPS antenna
  400/25 450/28 500/31 500/40 600/37 600/48 700/43 720/43
Furrower type PT
Working width [m] 4 4,5 5 5 6 6 7 7,2
Number of rows 4 4 4 4 4 4 4 4
Transport width [m] 3,05
Number of rows 25 28 31 40 37 48 43 43
Row spacing [cm] 16,0 16,1 16,1 12,5 16,2 12,5 16,3 16,7
Hopper capacity [l] 2000
Weight of machine with track eradicators [kg] (1) 1755 1780 1905 - 1940 - - 2125
Weight of machine with cultivator [kg] (2) 2095 2135 2295 - 2350 - - 2575
Reload height [cm] 230
Reload opening [cm] 110x105
Coupling category Cat. III
Minimum power required [hp] (3) 120 140 160 160 180 180
Main wheels/tyres Choose between wheels [10.75-15.3] and flotation wheels [340/55-16]
Metering unit drive ISOBUS electric
Speed connection Optional, see chap. "GNSS receivers"
Turbine drive Choose between mechanical with PTO drive shaft at 1000 rpm or hydraulic
Required hydraulic flow [l] 30
Tine spring harrow Two rows. First row of angled tines and second row of straight tines. Standard
Removable selector sieve Standard
Seed dose calibration kit Side, easy and precise
Controller/monitor From ISOBUS monitor (optional, see chap. "Control monitors")
Signal lights and work lights Standard
Depth control wheel equipment Standard: 2 wheels on wings (1 on each wing) and 0 wheels on central part
Main wheel scrapers Standard
Half-width cut-off  Optional, can be manual or automatic with GPS antenna
