SM-P

The SM-P is a direct seeder with a pressurised hopper with a capacity of 2,000 litres, available in various working widths ranging from 4 m to 7 m. It can also be used for conventional seeding and minimum tillage. Equipped with SM coulters and mounted on a 4-row seeding unit. Its chassis is made of high elastic limit steel and its distribution system is by means of a double external head.

Pressurised hopper.
For direct seeding, conventional seeding and minimum tillage.
Double outer distributor head.
Quick and easy calibration from ISOBUS monitor.
Interchangeable modular roller metering unit with ISOBUS electric drive.
ISOBUS electric drive.
Efficient hopper emptying.
Increased seed distribution capacity.
Reduced tractor hydraulic oil consumption.
Increased homogeneity of product distribution.
Optimum product preservation due to hermetic sealing.
Lower tractor fuel consumption.
Floating chassis in three sections.
Easy and intuitive operation from the tractor cab.



SM

Equipped with SM-1909, VESTA, SM-P, CERES and SD-3115. Multi-purpose seeding arm, for no till, minimum tillage and conventional seeding. Interchangeable Tungsten Carbide tip with high resistance to wear and very easy to change by means of a single screw.  The coulters behind the roller have individual depth adjustment. The 16 mm thick, high-strength steel arm allows seeding in the most demanding conditions, with reduced maintenance costs.


  1.     Double seeding pressure spring.
  2.     Arm built in high resistance steel.
  3.     Interchangeable coulter in anti-wear material and tungsten carbide tip.
  4.     Applicator boot with anti-wear treatment.
  5.     High resistance connection sleeve and flange.
  6.     Seed transport tube in anti-static material.
  7.     Individual pressure adjustment of the sowing coulter.
  8.     Individual depth adjustment (in adjustable versions).

    Siembra Directa

SM coulter for no till.

Features 400/25 500/31 600/24 600/30 600/37 700/43 800/32
Type of coupling SM
Working width (m) 4 5 6 6 6 7 8
Number of rows 4 4 4 3 4 4 4
Transport width (m) 3,05
Number of lines 25 31 24 30 37 43 32
Line spacing (cm) 16 16,129032 25 20 16,216216 16,27907 25
Hopper capacity (L) 2000
Weight of the machine with wheel mark eradicators (Kg) - - - - 2330 - -
Recharging height (cm) 256
Recharging opening (cm) 110X105
Coupler category Cat. III
Minimum power requirement (hp) (1) 120 140 160 160 160 180 180
Main wheels/tires Flotation wheels (340/55-16)
Proportioner drive Electric ISOBUS
Speed tapping 7 pins - Other options available in chapter "GSS receivers".
Turbine drive Choice of cardan mechanical drive at 1000 rpm or hydraulic drive
Required hydraulic flow (L) 30
Double harrow Optional - First row of angled tines and second row of straight tines
Removable selector screen Standard
Kit for seed rate calibration Standard: easy and accurate
Controller / Monitor From ISOBUS monitor (optional, see chapter "Control monitors")
Signal lights and work lights Standard
Depth control wheels on the equipment: Quantity 2 wheels on the folding parts and 2 wheels on the center part       2 casters on folding parts and 2 casters in the central part 4 wheels on folding parts and 2 wheels in central part
Scrapers on main wheels Standard
Trademark eradicator arms (installed on the machine) Optional - 3 wheel mark eradicator arms on each side of the machine
Half machine cutting Optional - Can be manual or automatic with GPS antenna
