VESTA P

The VESTA-P is a seed drill with a 7,000 litres pressurised hopper made of high-strength steel.
This allows for increased precision in distribution and application rates.
The Vesta P is designed to excel in no-till, minimum tillage and conventional seeding.

7,000 litre pressurised hopper
Optionally divisible for seed and fertiliser at a ratio of 60% and 40%.
Reduced turbine oil flow requirement
Metering of up to 3 products simultaneously
ISOBUS electric metering unit
Floating frame in three sections
For non-Till sowing, minimum tillage and conventional sowing

Pressurized hopper

The hopper of the VESTA-P is a 7000 litre pressurized hopper which can be optionally divided into a 60%/40% proportion for seed and fertiliser. The pressurized system gives a better homogeneity in the distribution of the product and an optimal preservation due to its hermetic sealing. This technology reduces the tractor's hydraulic oil and fuel consumption.

Double metering unit system

The combined seed and fertiliser spreader VESTA 2813 is equipped with two stainless steel distributors with easily interchangeable rollers for different products. This feature is standard on all ELEKTRA models.

Depth control on the lift

This system, which is fitted as standard on the VESTA, acts as a depth control on the linkage. It is adjusted by means of a plate and performs this function in addition to the main depth control system for the wheels of the sowing unit.
  800/32 800/40 800/48 900/36 900/44 900/54
Trailed hopper
Seed hopper capacity (L) 7000
Seed/fertiliser hopper capacity (L) 4380/2620
Wheels 560/60-R22.5
Recharge height (cm) 294
Reload opening (cm) 5 openings Ø56
Metering unit type With interchangeable modular rollers
Metering unit drive Electric ISOBUS
Speed socket 7 pins.
Turbine drive Hydraulic
Required hydraulic flow (L) 40
Controller/Monitor From ISOBUS monitor (not included as standard)
Total cutting of sowing Standard
Half-width shut-off Only available on machines with 2 distribution heads. Automatic when combined with GPS antenna.
Minimum power requirement (hp) 200
Removable selector sieve Standard
Signal lights and work lamps Standard
Dose calibration kit Standard
Hole diameter for coupling pin (mm) 32
Seeding equipment
Type of opening SM
Working width (m) 8 8 8 9 9 9
Number of rows 3 3 3 3 3 3
Transport width (m) 3,50 3,50
Number of rows 32 40 48 36 44 54
Row spacing (cm) 25,0 20,0 16,7 25,0 20,5 16,7
Double spring harrow Optional. First row of angled tines and second row of straight or angled tines.
Depth control wheels of the equipment: Quantity 4 wheels on wings and 4 wheels in the middle
Track eradicator coulters Optional
Approval for road transport Check available approvals by market
