VESTA

The VESTA 2813 is a 7,000 litre capacity seed drill with an amazing versatility that allows it to carry out all types of sowing as it can be equipped with a wide range of sowing equipments configurable in 2, 3 or 4 rows. Available in various working widths ranging from 5 m to 7.7 m and with electric or mechanical transmission.

Hopper with a capacity of 7,000 litres made of high-strength steel.
Optionally divisible for seed and fertiliser at a ratio of 60% and 40%.
Capacity for a third product by means of 2 optional hoppers of 205 litres each.
Floating chassis in three sections. ISOBUS mechanical or electrical metering by means of the ELEKTRA system.
Can be fitted with SM, PT, Double Disc and Tines Coulters.
Can also be fitted with 12-row PROSEM precision planters.


Multi-product divisible hopper

The hopper of the VESTA 2813 can optionally be configured in two parts for seed/fertiliser or seed/seed in a ratio of 60-40. In addition, it can be equipped with two outer hoppers for micro-granular products such as insecticides, micro-granular fertilisers, micro-irrigation, etc.

Double metering unit system

The combined seed and fertiliser spreader VESTA 2813 is equipped with two stainless steel distributors with easily interchangeable rollers for different products. This feature is standard on all ELEKTRA models.

Depth control on the lift

This system, which is fitted as standard on the VESTA, acts as a depth control on the linkage. It is adjusted by means of a plate and performs this function in addition to the main depth control system for the wheels of the sowing unit.
  600/30 680/34 760/38
Pulled hopper
Seed hopper capacity [l] 7000
Seed/fertiliser hopper capacity [l] 4380/2620
Wheels (2) 550/60-22.5
Reload height [cm] 284
Reload opening [cm] 196X252
Metering unit type Stainless steel volumetric
Metering unit drive Mechanical
Turbine drive Hydraulic
Required hydraulic flow [l] 40
Controller/monitor Standard. See characteristics in chap. "Control monitors"
Half-width shut-off (4) Optional.
Minimum power required [hp]  160 160 180
Removable selector sieve Standard
Signal lights and work lights Standard
Dose calibration kit Standard
Diameter of the hole for the coupling pin [mm] 32
Seeding equipment
Furrower type SM
Working width [m] 6 6,8 7,6
Number of rows 3 3 3
Transport width [m] 3,05
Number of rows 30 34 38
Row spacing [cm] 20,0 20,0 20,0
Double spring harrow Optional. First row of angled tines and second row of straight tines.
Depth control wheel equipment: number 2 wheels on wings and 2 wheels on central part 4 wheels on wings and 2 wheels on central part
Weight of hopper + seeding equipment [kg] - - -
Road transport type approval Check available type approvals per market
  500/31 600/37 700/43 770/47
Pulled hopper
Seed hopper capacity [l] 7000
Seed/fertiliser hopper capacity [l] 4380/2620
Wheels (2) 550/60-22.5
Reload height [cm] 284
Reload opening [cm] 196X252
Metering unit type Stainless steel volumetric
Metering unit drive Mechanical
Turbine drive Hydraulic
Required hydraulic flow [l] 40
Controller/monitor Standard. See characteristics in chap. "Control monitors".
Half-width shut-off (4) Optional.
Minimum power required [hp]  160 160 180 180
Removable selector sieve Standard
Signal lights and work lights Standard
Dose calibration kit Standard
Diameter of the hole for the coupling pin [mm] 32
Seeding equipment
Furrower type SM
Working width [m] 5 6 7 7,7
Number of rows 4 4 4 4
Transport width [m] 3,05
Number of rows 31 37 43 47
Row spacing [cm] 16,1 16,2 16,3 16,4
Double spring harrow Optional. First row of angled tines and second row of straight tines.
Depth control wheel equipment: number 2 wheels on wings and 2 wheels on central part 4 wheels on wings and 2 wheels on central part
Weight of hopper + seeding equipment [kg] - - - -
Road transport type approval Check available type approvals per market
  600/30 680/34 760/38
Pulled hopper
Seed hopper capacity [l] 7000
Seed/fertiliser hopper capacity [l] 4380/2620
Wheels (2) 550/60-22.5
Reload height [cm] 284
Reload opening [cm] 196X252
Metering unit type Interchangeable modular rollers
Metering unit drive ISOBUS electric
Turbine drive Hydraulic
Required hydraulic flow [l] 40
Controller/monitor From ISOBUS monitor (not included as standard, see chap. “Control monitors”)
Sowing cut-off Standard
Half-width shut-off Only available on machines with 2 distribution heads. Automatic if combined with a GPS antenna.
Minimum power required [hp]  160 160 180
Removable selector sieve Standard
Signal lights and work lights Standard
Dose calibration kit Standard
Diameter of the hole for the coupling pin [mm] 32
Seeding equipment
Furrower type SM
Working width [m] 6 6,8 7,6
Number of rows 3 3 3
Transport width [m] 3,05
Number of rows 30 34 38
Row spacing [cm] 20,0 20,0 20,0
Double spring harrow Optional. First row of angled tines and second row of straight tines.
Depth control wheel equipment: number 2 wheels on wings and 2 wheels on central part 4 wheels on wings and 2 wheels on central part
Weight of hopper + seeding equipment [kg] - - -
Road transport type approval Check available type approvals per market
  500/31 600/37 700/43 770/47
Pulled hopper
Seed hopper capacity [l] 7000
Seed/fertiliser hopper capacity [l] 4380/2620
Wheels (2) 550/60-22.5
Reload height [cm] 284
Reload opening [cm] 196X252
Metering unit type Interchangeable modular rollers
Metering unit drive ISOBUS electric
Turbine drive Hydraulic
Required hydraulic flow [l] 40
Controller/monitor From ISOBUS monitor (not included as standard, see chap. “GNSS receivers”)
Half-width shut-off (4) Optional. Automatic if combined with a GPS antenna
Minimum power required [hp]
Removable selector sieve Standard
Signal lights and work lights Standard
Dose calibration kit Standard
Diameter of the hole for the coupling pin [mm] 32
Seeding equipment
Furrower type SM
Working width [m] 5 6 7 7,7
Number of rows 4 4 4 4
Transport width [m] 3,05
Number of rows 31 37 43 47
Row spacing [cm] 16,1 16,2 16,3 16,4
Double spring harrow Optional. First row of angled tines and second row of straight tines.
Depth control wheel equipment: number 2 wheels on wings and 2 wheels on central part 4 wheels on wings and 2 wheels on central part
Weight of hopper + seeding equipment [kg] - - 5750 -
Road transport type approval Check available type approvals per market
