LONG TRANSPORT

Single-grain seed drills with K-element are the most sophisticated PROSEM seed drills with mechanical transmission. Their seeding element pressure regulation system is by means of a lever with 6 positions that allow precise adjustment of the seeding element setting.

Also available with K ELEKTRA elements which replace the transmission mechanism with an electric stepper motor to obtain the maximum performance and benefits of ISOBUS technology.

The chassis is rigid single bar with 150mm. square section on a 3m. wide transport trolley.
Working widths range from 600cm to 900cm. The distance between the sowing elements is fixed, which are fixed to the chassis by flanges.
to the chassis by means of flanges.


Same features and options as PROSEM fixed.
A system of wheels with hydraulic cylinders and a drawbar for connection to the tractor, to transport the machine longitudinally, reducing the transport width to 3 m.
  600/8 600/12 900/12
Frame type Single-bar rigid with fixed distance between units. Row units clamped to frame. Triple-bar rigid with fixed distance between units. Row units clamped to frame.
Coupling category Cat. II Cat. III
Row unit
Transport width [m] 2,90 2,90 3,00
Transport length [m] 7,20 7,20 10,50
Transport wheels 12.5/80-15.3 10.80-12
Number of rows 8 12 12
Row spacing [cm] (7) 45-80 45-50 45-75
Sowing distance changing Norton gearbox
Turbine drive Mechanical with PTO drive shaft at 540 rpm (hydraulic as an option)
PTO drive shaft Length 800 mm couplings Z6/Z6 (other options available)
Number of support or transmission wheels 2 support and transmission (3) 4 support and transmission
Wheel dimensions  23 x 10.5 23 x 8.5 23 x 10.5
Seed metering unit drive Mechanical
Sowing control Optional. (See chap. “Control monitors”)
Tractor hydraulic requirements Row marker: 1 SA / Hydraulic turbine: 1 SA + free return  ---  For transport 1 DA
Turbine vacuum gauge Analogue vacuum gauge as standard
Section control Optional
Seed hopper capacity [l] 50
Depth control wheels 400 x 115 (400 x 65 as an option, recommended for row spacing of less than 45 cm, see chap. "Options")
Closing wheels 2" rubber V as standard, for other options see chap. "Options"
Hydraulic row markers Optional, with flat disc to wheel (1)
Signal lights Optional
Sowing discs 1 set of "standard" discs included with the machine (see chap. "Sowing discs")
Micro hopper capacity [l] 14 litres per row
Micro metering unit drive Mechanical
Slug repellent hopper capacity [l] 14 litres per row
Slug repellent metering unit drive Mechanical
Small fertiliser hopper capacity [l] 4 x 300 l (Plastic) 6 x 300 l (Plastic)
Fertiliser metering unit drive Mechanical
Road transport type approval Check available type approvals per market
  600/8 600/12 900/12 900/18
Frame type Single-bar rigid with fixed distance between units. Row units clamped to frame. Triple-bar rigid with fixed distance between units. Row units clamped to frame.
Coupling category Cat. II Cat. III
Row unit PROSEM ELEKTRA
Transport width [m] 2,90 2,90 3,00 3,00
Transport length [m] 7,20 7,20 10,50
Transport wheels 12.5/80-15.3 10.80-12
Number of rows 8 12 12 18
Row spacing [cm] (7) 33-80 33-50 50-75 45-50
Sowing distance changing From ISOBUS monitor (not included as standard, see chap. “Control monitors”)
Turbine drive Mechanical with PTO drive shaft at 540 rpm (hydraulic as an option)
PTO drive shaft Length 800 mm couplings Z6/Z6 (other options available)
Number of support or transmission wheels 2 support (3) 4 support
Wheel dimensions  23 x 10.5 23 x 8.5 23 x 10.5
Seed metering unit drive ISOBUS electric
Speed connection 7-pin (see standard). Other options available in chap. "GNSS receivers"
Sowing control From ISOBUS monitor (not included as standard, see chap. "Control monitors")
ISOBUS compatibility Verify compatibility between ECU and ISOBUS terminal of the tractor - See chap. "ISOBUS compatibility questionnaires"
Tractor hydraulic requirements Row marker: 1 SA / Micro: 1 SA + free return / Slug repellent: 1 SA + free return / Hydraulic turbine: 1 SA + free return  ---  For transport: 1 DA
Turbine vacuum gauge Analogue vacuum gauge as standard
Section control From ISOBUS monitor (not included as standard, see chap. "Control monitors") - Requires license, speed connection and positioning
Variable dose From ISOBUS monitor (not included as standard, see chap. "Control monitors") - Requires license, speed connection, positioning and prescription maps
Energy generator Power pack with PTO alternator
Seed hopper capacity [l] 50
Depth control wheels 400 x 115 (400 x 65 as an option, recommended for row spacing of less than 45 cm, see chap."Options")
Closing wheels 2" rubber V as standard, for other options see chap. "Options"
Hydraulic row markers Optional, with flat disc to wheel (1)
Signal lights Optional
Sowing discs 1 set of "standard" discs included with the machine (see chap. "Sowing discs")
Fertiliser metering unit drive ISOBUS electric (requires a speed connection, optional)
Road transport type approval Check available type approvals per market
